| Standard |
ANSI/UL 864 |
| Primary AC |
120VAC @ 2.1 Amps 60hz or 220VAC @ 1.1Amps 50hz |
| Output DC |
24VDC @ 5.25 Amps (4 Amps available for system power) |
| Power Supply |
5.25 Amps integrated |
| Charger Current |
1.5 Amps max. |
| Dimensions |
14.5″ W x 24″ H x 5″ D |
| Weight |
31 lbs. (without batteries) |
| Weight |
31 lbs. (without batteries) |
| Color |
Red (optional gray) |
| Color |
Red (optional gray) |
| Material |
ABS/steel enclosure |
| Display |
8 line x 40 character LCD (320 characters total) |
| Network |
Dual RS485 ports (64 panels max.) |
| Zones |
500 network wide software zones per system |
| SLC loops |
2 or 4 (class A, “style 6 or 7” or class B, “style 4”) |
| Devices per loop |
127 sensors & modules, plus 127 analog sounder bases, 254 total |
| Addresses per panel |
(800 addresses + sub-addresses max. per panel) |
| NAC Outputs |
4) 2.5 Amps @ 24VDC (class B) |
| Relay Outputs |
(5) Form C 1 Amp @ 30VDC |
| Voltage Outputs |
(3) 500mA @ 24VDC |
| Aux. Power |
500mA @ 24VDC |
| Aux. Inputs |
(8) digital pull downs |
| PC Port / Printer |
RS232 |
| Operating Temp. |
32°F (0°C) 120°F (49°C) |
| Relative Humidity |
85% RH Non-Condensing |
